pMOD6-pGRR-r11-r10-yeGFP
(Plasmid #74368)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 74368 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMOD6
  • Backbone manufacturer
    Klavins Lab
  • Backbone size w/o insert (bp) 4208
  • Total vector size (bp) 5963
  • Vector type
    Yeast Expression, CRISPR, Synthetic Biology
  • Selectable markers
    URA3

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    yeGFP
  • Species
    Synthetic
  • Insert Size (bp)
    717
  • Promoter pGRR-r11-r10

Cloning Information

  • Cloning method Gibson Cloning
  • 5′ sequencing primer ccttaaccagattcgaaaagcggc
  • 3′ sequencing primer cggggcggggttattacgacat
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Please visit https://www.biorxiv.org/content/early/2016/03/02/041871 for bioRxiv preprint.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMOD6-pGRR-r11-r10-yeGFP was a gift from Eric Klavins (Addgene plasmid # 74368 ; http://n2t.net/addgene:74368 ; RRID:Addgene_74368)

  • For your References section:

    Robust digital logic circuits in eukaryotic cells with CRISPR/dCas9 NOR gates. Gander MW, Vrana JD, Voje Jr WE, Carothers JM, Klavins E. bioRxiv 041871 10.1101/041871
