pCI 9.0
(Plasmid
#74229)
-
PurposeLuminescent coincidence reporter with FLAG tags, FLuc-P2A-NLucPEST
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 74229 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepGL4.20
-
Backbone manufacturerPromega
- Backbone size w/o insert (bp) 5404
-
Modifications to backboneRemoval of FLuc2 from pGL4.20 via restriction digest with HindIII and BamHI. Insert Geneart (LifeTechnologies) synthesized 3xFLAGFLuc-P2A-3xFLAGNLucPEST using restriction cloning.
-
Vector typeMammalian Expression
-
Selectable markersPuromycin
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert name3xFlag-FLuc-P2A-3xFlag-NLucPEST
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
pCI 9.0 is a promoterless version of FLuc-P2A-NLucPEST coincidence reporter plasmid. pCI 9.0 contains a 5' MCS region for insertion of a promoter or response element of interest.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pCI 9.0 was a gift from James Inglese (Addgene plasmid # 74229 ; http://n2t.net/addgene:74229 ; RRID:Addgene_74229) -
For your References section:
Quantitative High-Throughput Screening Using a Coincidence Reporter Biocircuit. Schuck BW, MacArthur R, Inglese J. Curr Protoc Neurosci. 2017 Apr 10;79:5.32.1-5.32.27. doi: 10.1002/cpns.27. 10.1002/cpns.27 PubMed 28398644
