pJK545
(Plasmid #74225)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 74225 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pETDuet-1
  • Backbone manufacturer
    Novagen
  • Backbone size w/o insert (bp) 5420
  • Total vector size (bp) 6070
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    formylglycinamidine ribonucleotide synthetase, glutaminase subunit
  • Alt name
    purQ
  • Alt name
    AZ09_06385
  • Species
    Acetobacter aceti 1023
  • Mutation
    contains a silent mutation in Ala63 codon
  • GenBank ID
    KDE20460
  • Promoter T7

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer pET upstream primer
  • 3′ sequencing primer T7 terminator
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJK545 was a gift from T. J. Kappock (Addgene plasmid # 74225 ; http://n2t.net/addgene:74225 ; RRID:Addgene_74225)
