Addgene

pBP-T7RNAP
(Plasmid #74096)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 74096 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pSB1C3
  • Backbone manufacturer
    iGEM
  • Backbone size w/o insert (bp) 2044
  • Total vector size (bp) 4743
  • Modifications to backbone
    Modifications between XbaI and PstI from original pSB1C3 plasmid. CAT gene - C435G (nucleotide) - silent mutagenesis to remove BsmBI site
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    T7 RNAP
  • Alt name
    T7 RNA polymerase
  • Species
    Enterobacteria phage T7
  • Insert Size (bp)
    2652
  • GenBank ID
    GU071091.1
  • Promoter None

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BsaI (not destroyed)
  • 3′ cloning site BsaI (not destroyed)
  • 5′ sequencing primer tgccacctgacgtctaagaa; gaatacgctgaggctatcgcaac
  • 3′ sequencing primer attaccgcctttgagtgagc; cttagtgcccagcttgactttctc
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBP-T7RNAP was a gift from Paul Freemont (Addgene plasmid # 74096 ; http://n2t.net/addgene:74096 ; RRID:Addgene_74096)
  • For your References section:

    EcoFlex: A Multifunctional MoClo Kit for E. coli Synthetic Biology. Moore SJ, Lai HE, Kelwick RJ, Chee SM, Bell DJ, Polizzi KM, Freemont PS. ACS Synth Biol. 2016 May 2. 10.1021/acssynbio.6b00031 PubMed 27096716
