pWD509
(Plasmid #73739)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 73739 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pDONR221
  • Backbone manufacturer
    Thermo Fisher
  • Vector type
    Worm Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Top10
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    2xNLS-FLP-D5
  • Species
    C. elegans (nematode), S. cerevisiae (budding yeast)
  • Insert Size (bp)
    1467
  • Mutation
    G5D

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer M13 (-21) Forward
  • 3′ sequencing primer M13 Reverse
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pWD509 was a gift from Erik Jorgensen (Addgene plasmid # 73739 ; http://n2t.net/addgene:73739 ; RRID:Addgene_73739)

  • For your References section:

    SapTrap, a Toolkit for High-Throughput CRISPR/Cas9 Gene Modification in Caenorhabditis elegans. Schwartz ML, Jorgensen EM. Genetics. 2016 Feb 2. pii: genetics.115.184275. 10.1534/genetics.115.184275 PubMed 26837755
