pETM6-1B6-mCherry
(Plasmid
#73420)
-
PurposeReporter plasmid encoding mCherry, codon optimized for E. coli, transcriptionally driven by orthogonal T7-lac promoter variant 1B6.
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 73420 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepETM6
-
Backbone manufacturerKoffas Lab, Addgene Plasmid #49795
- Backbone size w/o insert (bp) 5147
-
Vector typeBacterial Expression, CRISPR, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namePromoter 1B6 (orthogonal T7-lac variant)
-
SpeciesSynthetic
- Promoter P1B6 (orthogonal T7-lac variant)
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer pBRrevBam
- 3′ sequencing primer T7 terminal (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Constructed using degenerate site directed mutagenesis of T7-lac promoter region. Also encodes mCherry reporter.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pETM6-1B6-mCherry was a gift from Mattheos Koffas (Addgene plasmid # 73420 ; http://n2t.net/addgene:73420 ; RRID:Addgene_73420) -
For your References section:
Rapid generation of CRISPR/dCas9-regulated, orthogonally repressible hybrid T7-lac promoters for modular, tuneable control of metabolic pathway fluxes in Escherichia coli. Cress BF, Jones JA, Kim DC, Leitz QD, Englaender JA, Collins SM, Linhardt RJ, Koffas MA. Nucleic Acids Res. 2016 Apr 13. pii: gkw231. 10.1093/nar/gkw231 PubMed 27079979
