C1-FKBP(F36V):mCherry-Akt2(K14A)
(Plasmid #72906)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 72906 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    C1
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    RAC-beta serine/threonine-protein kinase
  • Alt name
    Akt2
  • Species
    H. sapiens (human)
  • Mutation
    K14A mutation
  • Entrez Gene
    AKT2 (a.k.a. HIHGHH, PKBB, PKBBETA, PRKBB, RAC-BETA)
  • Tag / Fusion Protein
    • FKBP(F36V), mCherry (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NheI (unknown if destroyed)
  • 3′ cloning site BamHI (unknown if destroyed)
  • 5′ sequencing primer TAACAACTCCGCCCCATT
  • 3′ sequencing primer cctctacaaatgtggtatggc
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    C1-FKBP(F36V):mCherry-Akt2(K14A) was a gift from Ivan Yudushkin (Addgene plasmid # 72906 ; http://n2t.net/addgene:72906 ; RRID:Addgene_72906)
  • For your References section:

    Localization of mTORC2 activity inside cells. Ebner M, Sinkovics B, Szczygiel M, Ribeiro DW, Yudushkin I. J Cell Biol. 2017 Jan 31. pii: jcb.201610060. doi: 10.1083/jcb.201610060. 10.1083/jcb.201610060 PubMed 28143890
