zcUAS:PSD95.FingR-GFP-ZFC(CCR5TC)-KRAB(A)
(Plasmid
#72638)
-
PurposeTol2 based UAS modified with a CCR5TC binding site upstream of it, driving PSD95-FingR fused to GFP, CCR5TC zinc finger, and KRAB(A) repressor domain
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 72638 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepDONR 221
-
Backbone manufacturerInvitrogen
- Total vector size (bp) 6945
-
Vector typeGateway
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameUAS upstream of PSD95-FingR with ZFC(CCR5TC) and KRAB(A)
-
SpeciesM. musculus (mouse)
-
Insert Size (bp)2478
Cloning Information
- Cloning method Gateway Cloning
- 5′ sequencing primer T7
- 3′ sequencing primer T3 (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byfrom Don Arnold lab (Gross et al., Neuron, 2013): Plasmids pCAG_PSD95.FingR-eGFP-CCR5TC-KRAB(A) and pCAG_GPHN.FingR-mKate2-IL2RGTCKRAB(A) were obtained from Addgene (plasmids #46295 and #46297).
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Details of cloning are in:
Son et al., Scientific Reports, 2016. Transgenic FingRs for Live Mapping of Synaptic Dynamics in Genetically-Defined Neurons.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
zcUAS:PSD95.FingR-GFP-ZFC(CCR5TC)-KRAB(A) was a gift from Joshua Bonkowsky (Addgene plasmid # 72638 ; http://n2t.net/addgene:72638 ; RRID:Addgene_72638)
