pJK622
(Plasmid
#72538)
-
PurposeProduces Acetobacter aceti 1023 formylglycinamidine ribonucleotide synthetase large subunit with N-terminal His6-tag (H6AaPurL)
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 72538 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET28a
- Backbone size w/o insert (bp) 5369
- Total vector size (bp) 7498
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameformylglycinamidine ribonucleotide synthetase, large subunit
-
Alt namepurL
-
Alt nameAZ09_06390
-
SpeciesAcetobacter aceti 1023
-
GenBank IDKDE20461
- Promoter T7
-
Tag
/ Fusion Protein
- His6 (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site NdeI (not destroyed)
- 3′ cloning site XhoI (not destroyed)
- 5′ sequencing primer T7 promoter
- 3′ sequencing primer T7 terminator (Common Sequencing Primers)
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJK622 was a gift from T. J. Kappock (Addgene plasmid # 72538 ; http://n2t.net/addgene:72538 ; RRID:Addgene_72538)
