pJK635
(Plasmid #72473)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 72473 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pET28a
  • Backbone size (bp) 5381
  • Modifications to backbone
    replaced T7-tag sequence with TEV protease recognition site.
  • Vector type
    Bacterial Expression
  • Promoter T7
  • Tags / Fusion Proteins
    • His6 (N terminal on backbone)
    • TEV protease cleavage site (N terminal on backbone)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ sequencing primer T7 promoter
  • 3′ sequencing primer T7 terminator
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Alters N-terminal appendage to MAHHHHHHSSGVDLGTENLYFQSH for a gene cloned in NdeI site. After cleavage by TEV protease, results in Ser-His scar on the N-terminus.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJK635 was a gift from T. J. Kappock (Addgene plasmid # 72473 ; http://n2t.net/addgene:72473 ; RRID:Addgene_72473)
