pmCherry-C1_SEPT9 i1
(Plasmid #71622)

• Purpose: mammalian expression of human SEPT9 with an mCherry fusion
• Depositing Lab: Elias Spiliotis
• Publication: Dolat et al J Cell Biol. 2014 Oct 27;207(2):225-35. doi: 10.1083/jcb.201405050.

Backbone

• Vector backbone: pmCherry-C1
• Backbone manufacturer: Clontech
• Backbone size w/o insert (bp): 4700
• Total vector size (bp): 6500
• Vector type: Mammalian Expression
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Kanamycin, 50 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): DH5alpha
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: Septin 9
• Species: H. sapiens (human)
• Insert Size (bp): 1800
• Entrez Gene: SEPTIN9 (a.k.a. AF17q25, MSF, MSF1, NAPB, PNUTL4, SEPT9, SINT1, SeptD1)
• Promoter: CMV
• Tag / Fusion Protein:
  • mCherry (N terminal on backbone)

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: HindIII (unknown if destroyed)
• 3′ cloning site: SalI (unknown if destroyed)
• 5′ sequencing primer: mCherry-F
• 3′ sequencing primer: SV40pA-R

Resource Information

• Article Citing this Plasmid:
  • 1 Reference

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Takara Bio Limited Use Label License (formerly Clontech)
• Industry Terms:
  • Not Available to Industry
