pJK698
(Plasmid #71616)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 71616 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET23a
  • Backbone size w/o insert (bp) 3666
  • Total vector size (bp) 4176
  • Modifications to backbone
    replaced the BglII-NdeI segment with a PCR product encoding the T5 promoter
  • Vector type
    Bacterial Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    N5-carboxyaminoimidazole ribonucleotide mutase
  • Alt name
    purE
  • Alt name
    AZ09_02690
  • Species
    Acetobacter aceti 1023
  • Mutation
    changes tryptophan-34 to phenylalanine, tryptophan-165 to phenylalanine, additional N-terminal methionine
  • GenBank ID
    AAZ04483.1 KDE21029.1
  • Promoter T5

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site NdeI (not destroyed)
  • 3′ cloning site EcoRI (unknown if destroyed)
  • 5′ sequencing primer AmpR
  • 3′ sequencing primer T7 terminator
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Used to produce fluorotryptophan-containing protein.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pJK698 was a gift from T. J. Kappock (Addgene plasmid # 71616 ; http://n2t.net/addgene:71616 ; RRID:Addgene_71616)
