R777-E191 Hs.PRKAA1
(Plasmid #70475)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 70475 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pDonor-255
  • Backbone size w/o insert (bp) 2693
  • Vector type
    Gateway Entry Clone

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PRKAA1
  • Alt name
    NM_006251.5
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1680
  • Entrez Gene
    PRKAA1 (a.k.a. AMPK, AMPK alpha 1, AMPKa1)

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer M13F 23-mer (5'-CCCAGTCACGACGTTGTAAAACG)
  • 3′ sequencing primer attLR 23-mer (5'-TAACATCAGAGATTTTGAGACAC)
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    R777-E191 Hs.PRKAA1 was a gift from Dominic Esposito (Addgene plasmid # 70475 ; http://n2t.net/addgene:70475 ; RRID:Addgene_70475)
