Addgene

pKG139
(Plasmid #69755)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 69755 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pIC194
  • Backbone manufacturer
    Arshad Desai (Addgene plasmid# 44433)
  • Vector type
    Mammalian Expression, Retroviral

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CENP-C
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    2832
  • Mutation
    L341F, N570D relative to NP_001803.2 (numbering based on CENP-C without tag)
  • Entrez Gene
    CENPC (a.k.a. CENP-C, CENPC1, MIF2, hcp-4)
  • Tag / Fusion Protein
    • mCherry-TEV-S (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site EcoRI (not destroyed)
  • 5′ sequencing primer mCherry-F
  • 3′ sequencing primer SV40pA-R
  • (Common Sequencing Primers)

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Discrepancies between the plasmid and the NCBI reference sequence for CENP-C exist, however, the plasmid is predicted to function as described in the associated publication.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pKG139 was a gift from Iain Cheeseman (Addgene plasmid # 69755 ; http://n2t.net/addgene:69755 ; RRID:Addgene_69755)
  • For your References section:

    Induced ectopic kinetochore assembly bypasses the requirement for CENP-A nucleosomes. Gascoigne KE, Takeuchi K, Suzuki A, Hori T, Fukagawa T, Cheeseman IM. Cell. 2011 Apr 29;145(3):410-22. doi: 10.1016/j.cell.2011.03.031. 10.1016/j.cell.2011.03.031 PubMed 21529714
