MAP3K5-TAP
(Plasmid #69726)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 69726 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone manufacturer
    Life Technologies
  • Backbone size w/o insert (bp) 5428
  • Total vector size (bp) 9544
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Apoptosis signal-regulating kinase 1
  • Alt name
    MAP3K5
  • Alt name
    ASK1
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    9544
  • Entrez Gene
    MAP3K5 (a.k.a. ASK1, MAPKKK5, MEKK5)
  • Promoter CMV
  • Tag / Fusion Protein
    • HA-FLAG tag (C terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BmtI (not destroyed)
  • 3′ cloning site XbaI (not destroyed)
  • 5′ sequencing primer T7
    • (Common Sequencing Primers)

Resource Information

  • A portion of this plasmid was derived from a plasmid made by
    Original gene received from Ichijo group.
  • Articles Citing this Plasmid

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    MAP3K5-TAP was a gift from Daniel Liebler (Addgene plasmid # 69726 ; http://n2t.net/addgene:69726 ; RRID:Addgene_69726)
