pJBL-RNAOUTA4
(Plasmid
#69458)
-
PurposeRNA-OUT A4 variant - antisense (UTR sequence from Mutalik et al., Nat. Chem. Biol., 2012)
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 69458 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonecustom
-
Backbone manufacturerN/A
- Backbone size w/o insert (bp) 2100
- Total vector size (bp) 2250
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameRNA-OUT A4
-
Alt nameIS10 counter-transcript (mutated A4 variant)
-
SpeciesSynthetic
-
Insert Size (bp)140
- Promoter J23119
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer aaccattattatcatgacattaac (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Mutated from sequence obtained from Arkin Lab (UC Berkeley)
**Contains ColE1 origin (not automatically annotated by Addgene)**
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJBL-RNAOUTA4 was a gift from Julius Lucks (Addgene plasmid # 69458 ; http://n2t.net/addgene:69458 ; RRID:Addgene_69458) -
For your References section:
Simultaneous characterization of cellular RNA structure and function with in-cell SHAPE-Seq. Watters KE, Abbott TR, Lucks JB. Nucleic Acids Res. 2015 Sep 8. pii: gkv879. 10.1093/nar/gkv879 PubMed 26350218
