pKB01-PssbB-mKate2
(Plasmid
#69105)
-
PurposeExpresses mKate2 (codon adapted for Streptococcus pneumoniae); under control of CSP inducible promoter PssbB. Plasmid integrates in S. pneumoniae bgaA locus by double cross-over.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 69105 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepPPP1
- Total vector size (bp) 8507
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namemKate2
-
SpeciesSynthetic
-
Insert Size (bp)696
-
GenBank IDKJ908191 KJ908191
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site EcoRI (unknown if destroyed)
- 3′ cloning site BcuI (unknown if destroyed)
- 5′ sequencing primer PP2_MCS (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pKB01-PssbB-mKate2 was a gift from Jan-Willem Veening (Addgene plasmid # 69105 ; http://n2t.net/addgene:69105 ; RRID:Addgene_69105) -
For your References section:
Red fluorescent proteins for gene expression and protein localization studies in Streptococcus pneumoniae and efficient transformation with Gibson assembled DNA. Beilharz K, van Raaphorst R, Kjos M, Veening JW. Appl Environ Microbiol. 2015 Aug 7. pii: AEM.02033-15. 10.1128/AEM.02033-15 PubMed 26253684
