pKB01_tagRFP
(Plasmid
#69103)
-
PurposeExpresses tagRFP (codon adapted for Streptococcus pneumoniae); under control of Zinc inducible promoter PZn. Plasmid integrates in S. pneumoniae bgaA locus by double cross-over.
-
Depositing Lab
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 69103 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepPPP1
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nametagRFP
-
SpeciesSynthetic
-
Insert Size (bp)696
-
GenBank IDKJ908188
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pKB01_tagRFP was a gift from Jan-Willem Veening (Addgene plasmid # 69103 ; http://n2t.net/addgene:69103 ; RRID:Addgene_69103) -
For your References section:
Red fluorescent proteins for gene expression and protein localization studies in Streptococcus pneumoniae and efficient transformation with Gibson assembled DNA. Beilharz K, van Raaphorst R, Kjos M, Veening JW. Appl Environ Microbiol. 2015 Aug 7. pii: AEM.02033-15. 10.1128/AEM.02033-15 PubMed 26253684
