PurposeURA+ yeast shuttle vector containing yZ3EV TF cassette and a Z3pr driving expression of yEGFP
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 69100 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepRS416
- Total vector size (bp) 7796
-
Modifications to backboneAddition of yZ3EV cassette and Z3pr; CYC1 3'UTR is still there from the parent vector (pRS416GPD)
-
Vector typeYeast Expression
-
Selectable markersURA3
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Top10
-
Copy numberHigh Copy
Gene/Insert 1
-
Gene/Insert nameyZ3EV cassette
-
SpeciesSynthetic
-
Insert Size (bp)2021
Gene/Insert 2
-
Gene/Insert nameZ3 promoter
-
SpeciesSynthetic
-
Insert Size (bp)699
Gene/Insert 3
-
Gene/Insert nameyEGFP
-
SpeciesSynthetic
-
Insert Size (bp)717
Resource Information
-
Supplemental Documents
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pRS416-yZ3EV-Z3pr-yEGFP (RB3579) was a gift from David Botstein (Addgene plasmid # 69100 ; http://n2t.net/addgene:69100 ; RRID:Addgene_69100)
