pCR3-FLAG-Gephyrin GC
(Plasmid #68818)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 68818 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pCR3
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5100
  • Total vector size (bp) 6100
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Gephyrin
  • Alt name
    GPHN
  • Species
    R. norvegicus (rat)
  • Insert Size (bp)
    1000
  • Mutation
    NIL
  • GenBank ID
    NM022865.3
  • Entrez Gene
    Gphn (a.k.a. Geph)
  • Promoter CMV
  • Tag / Fusion Protein
    • 3xFLAG (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site HindIII (not destroyed)
  • 3′ cloning site KpnI (not destroyed)
  • 5′ sequencing primer T7
  • 3′ sequencing primer SP6
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCR3-FLAG-Gephyrin GC was a gift from Shiva Tyagarajan (Addgene plasmid # 68818 ; http://n2t.net/addgene:68818 ; RRID:Addgene_68818)

  • For your References section:

    Extracellular signal-regulated kinase and glycogen synthase kinase 3beta regulate gephyrin postsynaptic aggregation and GABAergic synaptic function in a calpain-dependent mechanism. Tyagarajan SK, Ghosh H, Yevenes GE, Imanishi SY, Zeilhofer HU, Gerrits B, Fritschy JM. J Biol Chem. 2013 Apr 5;288(14):9634-47. doi: 10.1074/jbc.M112.442616. Epub 2013 Feb 13. 10.1074/jbc.M112.442616 PubMed 23408424
