pRT802
(Plasmid
#68113)
-
PurposeIntegration vector derived from Streptomyces phage phiBT1. Kanamycin resistance gene, oriT, ColE1 origin of replication.
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 68113 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepSET152
-
Modifications to backbonePhiC31 int/attP replaced with phiBT1 int/attP
-
Vector typeStreptomyces integrating vector
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert 1
-
Gene/Insert nameaac3(IV)
-
Alt nameapramycin fragment
-
SpeciesE. coli
-
Insert Size (bp)29
Gene/Insert 2
-
Gene/Insert nameaph11
-
Alt nameaminoglycoside phosphotransferase
-
Speciestransposon Tn5
-
Insert Size (bp)925
Gene/Insert 3
-
Gene/Insert nameoriT
-
Alt nameorigin of transfer
-
SpeciesE. coli
Gene/Insert 4
-
Gene/Insert nameattP
-
Alt namephage attachment site
-
Speciesbacteriophage phiBT1
-
Insert Size (bp)51
Gene/Insert 5
-
Gene/Insert nameint
-
Alt namephiBT1 integrase
-
Speciesbacteriophage phiBT1
-
Insert Size (bp)1430
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
For research using this plasmid, please acknowledge the depositing laboratory and associated citation.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pRT802 was a gift from Maggie Smith (Addgene plasmid # 68113 ; http://n2t.net/addgene:68113 ; RRID:Addgene_68113) -
For your References section:
Integration site for Streptomyces phage phiBT1 and development of site-specific integrating vectors. Gregory MA, Till R, Smith MC. J Bacteriol. 2003 Sep;185(17):5320-3. PubMed 12923110
