pAAV-hsyn-flex-dsRed-shvgat
(Plasmid #67845)

• Purpose: Expresses shRNA to the vesicular GABA transporter VGAT. Cre dependent expression by flex switch
• Depositing Lab: William Wisden
• Publication: Yu et al Neuron. 2015 Jun 17. pii: S0896-6273(15)00516-4. doi: 10.1016/j.neuron.2015.06.003.

Backbone

• Vector backbone: pUC
• Backbone size w/o insert (bp): 2700
• Total vector size (bp): 5908
• Vector type: Mammalian Expression, Mouse Targeting, AAV, RNAi, Cre/Lox

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): NEB Stable
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: AAV-hsyn-flexed-dsRed-miR30-vgat2.shRNA
• gRNA/shRNA sequence: VGAT
• Species: M. musculus (mouse), Synthetic
• Promoter: h-synapsin

Cloning Information

• Cloning method: Restriction Enzyme
• 5′ cloning site: AscI (not destroyed)
• 3′ cloning site: NheI (not destroyed)
• 5′ sequencing primer: CGTAATGCAGAAGAAGACTATG
• 3′ sequencing primer: CCATGTAGATGGACTTGAACTC

Resource Information

• A portion of this plasmid was derived from a plasmid made by: this plasmid is modified from the pRIME system. See: Stegmeier, F., Hu, G., Rickles, R.J., Hannon, G.J., and Elledge, S.J. (2005). A lentiviral microRNA-based system for single-copy polymerase II-regulated RNA interference in mammalian cells. Proc. Natl. Acad. Sci. USA 102, 13212–13217 We used The pPRIME-CMV-dsRed-FF3 vector, a gift from Stephen Elledge (Addgene plasmid 11664), as the building block to make the AAV-hsyn-flex-dsRed-miR30-vgat2.shRNA plasmid.
• Articles Citing this Plasmid:
  • 2 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
  • Takara Bio Limited Use Label License (formerly Clontech)
• Industry Terms:
  • Not Available to Industry

Depositor Comments

this plasmid is modified from the pRIME system. See:
Stegmeier, F., Hu, G., Rickles, R.J., Hannon, G.J., and Elledge, S.J. (2005). A
lentiviral microRNA-based system for single-copy polymerase II-regulated
RNA interference in mammalian cells. Proc. Natl. Acad. Sci. USA 102,
13212–13217
We used The pPRIME-CMV-dsRed-FF3 vector, a gift from Stephen Elledge (Addgene plasmid 11664), as the building block to make the AAV-hsyn-flex-dsRed-miR30-vgat2.shRNA plasmid.

transgene expression is Cre-dependent; contains flex switch

All the enzymes are unique cutters, except EcoRI and XhoI, the insert dsRed-shRNA can be retrieved using AscI and NheI, giving 1.2kb and 4.8kb bands.

The insert was read using primers in the dsred sequence:
dsred 410: CGTAATGCAGAAGAAGACTATG
dsred 530R: CCATGTAGATGGACTTGAACTC
