Purpose(Empty Backbone) cloning of sgRNAs for expression in plants
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 66199 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonebased on pUC18
-
Vector typeCloning Vector
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH10B
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameNone
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
accession number KR029098. By Omega-PCR cloning, an E. coli promoter-LacZ sequence (198 bp in length) was inserted. The LacZ marker gene can be used to facilitate selection of Escherichia coli positive CRISPR/Cas9 clones carrying the sgRNA expression cassettes.
Please see our published protocol for using these plasmids. Ma, X. and Liu, Y.-G. 2016. CRISPR/Cas9-based multiplex genome editing in monocot and dicot plants. Curr. Protoc. Mol. Biol. 115:31.6.1-31.6.21. http://onlinelibrary.wiley.com/doi/10.1002/cpmb.10/abstract doi: 10.1002/cpmb.10
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pYLsgRNA-AtU3b/LacZ was a gift from Yao-Guang Liu (Addgene plasmid # 66199 ; http://n2t.net/addgene:66199 ; RRID:Addgene_66199) -
For your References section:
A robust CRISPR/Cas9 system for convenient, high-efficiency multiplex genome editing in monocot and dicot plants. Ma X, Zhang Q, Zhu Q, Liu W, Chen Y, Qiu R, Wang B, Yang Z, Li H, Lin Y, Xie Y, Shen R, Chen S, Wang Z, Chen Y, Guo J, Chen L, Zhao X, Dong Z, Liu YG. Mol Plant. 2015 Apr 24. pii: S1674-2052(15)00204-X. doi: 10.1016/j.molp.2015.04.007. 10.1016/j.molp.2015.04.007 PubMed 25917172
