pLenti-Rac1-2G
(Plasmid #66111)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 66111 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pLenti pRRL-SV40(puro)_CMV(mcs)
  • Backbone size w/o insert (bp) 7711
  • Total vector size (bp) 8110
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers
    Puromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    Second generation Rac1 FRET biosensor
  • Alt name
    Rac1-2G
  • Species
    Synthetic
  • Insert Size (bp)
    2576
  • Promoter CMV
  • Tag / Fusion Protein
    • His-Myc (N terminal on insert)

Cloning Information

  • Cloning method Ligation Independent Cloning
  • 5′ sequencing primer CGACTCTAGAGGATCCGGAGATATA
  • 3′ sequencing primer CTAGACTGCAGGATCCTGGTGATGGTGATGG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLenti-Rac1-2G was a gift from Olivier Pertz (Addgene plasmid # 66111 ; http://n2t.net/addgene:66111 ; RRID:Addgene_66111)

  • For your References section:

    SrGAP2-Dependent Integration of Membrane Geometry and Slit-Robo-Repulsive Cues Regulates Fibroblast Contact Inhibition of Locomotion. Fritz RD, Menshykau D, Martin K, Reimann A, Pontelli V, Pertz O. Dev Cell. 2015 Sep 29. pii: S1534-5807(15)00582-1. doi: 10.1016/j.devcel.2015.09.002. 10.1016/j.devcel.2015.09.002 PubMed 26439400
