pCH119
(Plasmid #65954)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 65954 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pSC101

Growth in Bacteria

  • Bacterial Resistance(s)
    Chloramphenicol, 25 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    XL1 Blue
  • Copy number
    Low Copy

Gene/Insert 1

  • Gene/Insert name
    RhlR
  • Insert Size (bp)
    966
  • Entrez Gene
    rhlR (a.k.a. PA3477)
  • Promoter pTrc*

Cloning Information for Gene/Insert 1

  • Cloning method Unknown
  • 5′ sequencing primer agaaatactagtatgaggaatgacggaggctttttgc
  • 3′ sequencing primer accagaaagcttattagatgagacccagcgccgcg
  • (Common Sequencing Primers)

Gene/Insert 2

  • Gene/Insert name
    CinR
  • Insert Size (bp)
    726
  • GenBank ID
    AF210630.1
  • Promoter pTrc*

Cloning Information for Gene/Insert 2

  • Cloning method Unknown
  • 5′ sequencing primer agaaatactagtatgattgagaatacctatagcgaaaagttcgag
  • 3′ sequencing primer gcgttcgagctctcagggattgatgatgcgcaattgaac
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Integrated into the attP site

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCH119 was a gift from Matthew Bennett (Addgene plasmid # 65954 ; http://n2t.net/addgene:65954 ; RRID:Addgene_65954)
  • For your References section:

    SYNTHETIC BIOLOGY. Emergent genetic oscillations in a synthetic microbial consortium. Chen Y, Kim JK, Hirning AJ, Josic K, Bennett MR. Science. 2015 Aug 28;349(6251):986-9. doi: 10.1126/science.aaa3794. 10.1126/science.aaa3794 PubMed 26315440
