pC239
(Plasmid
#65953)
-
PurposeN2 inverter plasmid for two-strain system
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 65953 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonep15A
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Spectinomycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)XL1 Blue
-
Copy numberLow Copy
Gene/Insert 1
-
Gene/Insert nameAiiA
-
SpeciesBacillus thuringiensis
-
Insert Size (bp)786
- Promoter pCin*
-
Tag
/ Fusion Protein
- LAA tagged (C terminal on insert)
Cloning Information for Gene/Insert 1
- Cloning method Unknown
- 5′ sequencing primer gagaaaactagtatgacagtaaagaaactttatttcatcccagcag
- 3′ sequencing primer ggaccagagctcttattacgctgcaagggcgtaattttcgtcgttcgctgc (Common Sequencing Primers)
Gene/Insert 2
-
Gene/Insert nameLacI
-
Insert Size (bp)1122
- Promoter pCin
-
Tag
/ Fusion Protein
- LAA tagged (C terminal on insert)
Cloning Information for Gene/Insert 2
- Cloning method Unknown
- 5′ sequencing primer gagaaaactagtatgaaaccagtaacgttatacgatgtcgcag
- 3′ sequencing primer taggggaagcttttattacgctgcaagggcgtaattttcgtcgttcgctgc (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pC239 was a gift from Matthew Bennett (Addgene plasmid # 65953 ; http://n2t.net/addgene:65953 ; RRID:Addgene_65953) -
For your References section:
SYNTHETIC BIOLOGY. Emergent genetic oscillations in a synthetic microbial consortium. Chen Y, Kim JK, Hirning AJ, Josic K, Bennett MR. Science. 2015 Aug 28;349(6251):986-9. doi: 10.1126/science.aaa3794. 10.1126/science.aaa3794 PubMed 26315440
