pTPGI_dCas9
(Plasmid #64279)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 64279 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pRS304
  • Total vector size (bp) 10900
  • Vector type
    Yeast Expression
  • Selectable markers
    TRP1

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Yeast-optimized dCas9
  • Species
    S. cerevisiae (budding yeast)
  • Insert Size (bp)
    4101
  • Mutation
    D10A & H840A relative to S. pyogenes Cas9
  • Promoter pTPGI
  • Tag / Fusion Protein
    • SV40 NLS (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BamHI (not destroyed)
  • 3′ cloning site SalI (not destroyed)
  • 5′ sequencing primer CAAATTAACAACCATAGGATGATAATGCG
  • 3′ sequencing primer GTTACATGCGTACACGCGTCTGTACAG
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pTPGI_dCas9 was a gift from Timothy Lu (Addgene plasmid # 64279 ; http://n2t.net/addgene:64279 ; RRID:Addgene_64279)

  • For your References section:

    Tunable and Multifunctional Eukaryotic Transcription Factors Based on CRISPR/Cas. Farzadfard F, Perli SD, Lu TK. ACS Synth Biol. 2013 Sep 11. 10.1021/sb400081r PubMed 23977949
