pSR33.4r
(Plasmid #63198)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 63198 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pACYCDuet-1
  • Total vector size (bp) 6201
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Top10
  • Copy number
    High Copy

Gene/Insert 1

  • Gene/Insert name
    Cph8
  • Species
    Synthetic
  • Insert Size (bp)
    2235

Gene/Insert 2

  • Gene/Insert name
    Ho1
  • Species
    Synechocystis sp. PCC 6803
  • Insert Size (bp)
    723

Gene/Insert 3

  • Gene/Insert name
    PcyA
  • Species
    Synechocystis sp. PCC 6803
  • Insert Size (bp)
    747

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pSR33.4r was a gift from Jeffrey Tabor (Addgene plasmid # 63198 ; http://n2t.net/addgene:63198 ; RRID:Addgene_63198)

  • For your References section:

    Refactoring and optimization of light-switchable escherichia coli two-component systems. Schmidl SR, Sheth RU, Wu A, Tabor JJ. ACS Synth Biol. 2014 Nov 21;3(11):820-31. doi: 10.1021/sb500273n. Epub 2014 Oct 11. 10.1021/sb500273n PubMed 25250630
