PurposeContains expanded CGG repeats (99 repeats) within the 5'UTR of FMR1 as found in the Fragile X Tremor Ataxia Syndrome (FXTAS).
-
Depositing Lab
-
Publication
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 63089 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneunknown
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 50 μg/mL
-
Growth TemperatureRoom Temperature
-
Growth Strain(s)Stbl3
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameexpanded CGG repeats (99 repeats) within the 5'UTR of FMR1
-
SpeciesH. sapiens (human)
-
Entrez GeneFMR1 (a.k.a. FMRP, FRAXA, POF, POF1)
- Promoter CMV
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer CMV-F (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Addgene Notes
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Should be amplified in STBL3 bacteria and grown at Room temperature to keep the repeats stable.
This construct allows translation of CGG repeats into 99 glycine due to a near cognate ATG codon upstream of the repeat in the 5'UTR of FMR1 (an ACG codon that initiates weakly translation).
This plasmid should be verified via restriction analysis. Multiple colonies may need to be screened to isolate the correct construct.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
5'UTR CGG 99x FMR1 was a gift from Nicolas Charlet-Berguerand (Addgene plasmid # 63089 ; http://n2t.net/addgene:63089 ; RRID:Addgene_63089)
