pJZC572
(Plasmid
#62318)
-
PurposesgRNA with 1x com for yeast cells
-
Depositing Labs
-
Sequence Information
Ordering
This material is available to academics and nonprofits only.
| Item | Catalog # | Description | Quantity | Price (USD) | |
|---|---|---|---|---|---|
| Plasmid | 62318 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 | |
Backbone
-
Vector backbonepRS416
-
Vector typeYeast Expression
-
Selectable markersURA3
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Stbl3
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert namesgRNA + 1x com RNA binding module
-
gRNA/shRNA sequenceACTTTTCTCTATCACTGATA
- Promoter SNR52
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer tgtaaaacgacggccagt (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
How to cite this plasmid
( Back to top)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pJZC572 was a gift from Wendell Lim & Stanley Qi (Addgene plasmid # 62318 ; http://n2t.net/addgene:62318 ; RRID:Addgene_62318) -
For your References section:
Engineering Complex Synthetic Transcriptional Programs with CRISPR RNA Scaffolds. Zalatan JG, Lee ME, Almeida R, Gilbert LA, Whitehead EH, La Russa M, Tsai JC, Weissman JS, Dueber JE, Qi LS, Lim WA. Cell. 2014 Dec 18. pii: S0092-8674(14)01570-0. doi: 10.1016/j.cell.2014.11.052. 10.1016/j.cell.2014.11.052 PubMed 25533786
