PurposephageC31 integrase-expressing helper plasmid for Anopheles transgenesis, vasa promoter
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 62299 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepDONR P4r-P3r
-
Backbone manufacturerInvitrogen
- Backbone size w/o insert (bp) 2700
- Total vector size (bp) 7990
-
Vector typeInsect Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert namephageC31 integrase under control of vasa promoter and terminator
-
SpeciesStreptomyces phage C31
-
Insert Size (bp)5287
- Promoter vasa
-
Tags
/ Fusion Proteins
- SV40 NLS (N terminal on insert)
- HA (N terminal on insert)
Cloning Information
- Cloning method Unknown
- 5′ sequencing primer M13F
- 3′ sequencing primer M13R (Common Sequencing Primers)
Resource Information
-
Supplemental Documents
-
A portion of this plasmid was derived from a plasmid made byintegrase from K Basler laboratory vasa regulatory regions from A Crisanti laboratory
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pENTR R4-vas2-integrase-R3 was a gift from Eric Marois (Addgene plasmid # 62299 ; http://n2t.net/addgene:62299 ; RRID:Addgene_62299) -
For your References section:
Tools for Anopheles gambiae Transgenesis. Volohonsky G, Terenzi O, Soichot J, Naujoks DA, Nolan T, Windbichler N, Kapps D, Smidler AL, Vittu A, Costa G, Steinert S, Levashina EA, Blandin SA, Marois E. G3 (Bethesda). 2015 Apr 13. pii: g3.115.016808. doi: 10.1534/g3.115.016808. 10.1534/g3.115.016808 PubMed 25869647
