pCMU-MTUBr
(Plasmid #61196)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 61196 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pK7m34GW
  • Vector type
    Plant Expression
  • Selectable markers
    Kanamycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Spectinomycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    MAP-MBD
  • Insert Size (bp)
    1260
  • Promoter AtUBQ10
  • Tag / Fusion Protein
    • mCherry

Cloning Information

  • Cloning method Gateway Cloning
  • 5′ sequencing primer TCCCGGCAAGAAGAAGCA
  • 3′ sequencing primer GGCACCTCCTGCAGGAAA
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMU-MTUBr was a gift from Maria Harrison (Addgene plasmid # 61196 ; http://n2t.net/addgene:61196 ; RRID:Addgene_61196)

  • For your References section:

    A set of fluorescent protein-based markers expressed from constitutive and arbuscular mycorrhiza-inducible promoters to label organelles, membranes and cytoskeletal elements in Medicago truncatula. Ivanov S, Harrison MJ. Plant J. 2014 Oct 20. doi: 10.1111/tpj.12706. 10.1111/tpj.12706 PubMed 25329881
