GA-NES
(Plasmid #61018)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 61018 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1
  • Backbone size w/o insert (bp) 5500
  • Total vector size (bp) 6256
  • Modifications to backbone
    Multi cloning sites has been replaced by a customized sequence, which is compatible to the reading frame of vector pBAD hisB.
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    ddGFP A
  • Alt name
    dimerization dependent green fluorescent protein (ddGFP) copy A
  • Species
    Synthetic; synthetic construct
  • Insert Size (bp)
    756
  • GenBank ID
    KP030820
  • Promoter CMV
  • Tags / Fusion Proteins
    • NES sequence LALKLAGLDIGS (C terminal on insert)
    • HindIII site (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site HindIII (not destroyed)
  • 5′ sequencing primer T7 Promoter forward primer
  • 3′ sequencing primer BGH Reverse primers
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    GA-NES was a gift from Robert Campbell (Addgene plasmid # 61018 ; http://n2t.net/addgene:61018 ; RRID:Addgene_61018)

  • For your References section:

    Ratiometric biosensors based on dimerization-dependent fluorescent protein exchange. Ding Y, Li J, Enterina JR, Shen Y, Zhang I, Tewson PH, Mo GC, Zhang J, Quinn AM, Hughes TE, Maysinger D, Alford SC, Zhang Y, Campbell RE. Nat Methods. 2015 Jan 26. doi: 10.1038/nmeth.3261. 10.1038/nmeth.3261 PubMed 25622108
