pET28a-CohIII-CBM-HIS-ybbR
(Plasmid
#60866)
-
PurposeCharacteristic fingerprint molecule fused to cohesin type III domain to perform single molecule force spectroscopy experiments; covalently immobilized via introduced ybbR tag
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 60866 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET28a
-
Backbone manufacturerNovagen
- Backbone size w/o insert (bp) 5216
- Total vector size (bp) 6527
-
Vector typeBacterial Expression
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberLow Copy
Gene/Insert 1
-
Gene/Insert nameCohIII
-
Alt namecohesin type III
-
SpeciesRuminococcus flavefaciens
-
Insert Size (bp)615
- Promoter T7
Cloning Information for Gene/Insert 1
- Cloning method Gibson Cloning
- 5′ sequencing primer T7 Forward
- 3′ sequencing primer T7 Reverse (Common Sequencing Primers)
Gene/Insert 2
-
Gene/Insert nameCBM
-
Alt namecarbohydrate binding module
-
SpeciesClostridium thermocellum
-
Insert Size (bp)696
-
MutationCysteine 63 to Serine in CBM module
- Promoter T7
-
Tags
/ Fusion Proteins
- 6xHIS (C terminal on insert)
- ybbR (C terminal on insert)
- HRV 3C (C terminal on backbone)
Cloning Information for Gene/Insert 2
- Cloning method Gibson Cloning
- 5′ sequencing primer T7 Forward
- 3′ sequencing primer T7 Reverse (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byWe thankfully received the cohesin and CBM domain from Professor Edward Bayer (Department of Biological Chemistry, Weizmann Institute of Science, Israel) as recently described in this paper: "Atypical cohesin-dockerin complex responsible for cell surface attachment of cellulosomal components: binding fidelity, promiscuity, and structural buttresses."Salama-Alber Orly, Jobby Maroor K., Chitayat Seth, Smith Steven P., White Bryan A., Shimon Linda J. W., Lamed Raphael, Frolow Felix, Bayer Edward A. (The Journal of biological chemistry, 2013, 288 (23).
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pET28a-CohIII-CBM-HIS-ybbR was a gift from Hermann Gaub (Addgene plasmid # 60866 ; http://n2t.net/addgene:60866 ; RRID:Addgene_60866) -
For your References section:
Ultrastable cellulosome-adhesion complex tightens under load. Schoeler C, Malinowska KH, Bernardi RC, Milles LF, Jobst MA, Durner E, Ott W, Fried DB, Bayer EA, Schulten K, Gaub HE, Nash MA. Nat Commun. 2014 Dec 8;5:5635. doi: 10.1038/ncomms6635. 10.1038/ncomms6635 PubMed 25482395
