pET:ACAT:GFP
(Plasmid
#60740)
-
PurposeA modified pET28 driving expression of GFP, biobrick part Bba_E0040. No LacO site downstream of PT7. T7 promoter has base pairs 'ACAT' between -11 and -8.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 60740 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepET-28b
- Backbone size w/o insert (bp) 5273
- Total vector size (bp) 5993
-
Modifications to backboneNo lacO site downstream of T7 promoter. Nucleotides between -11 and -8 are 'ACAT'.
-
Vector typeBacterial Expression, Synthetic Biology
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH10B
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameGFP
-
Alt nameBba_E0040
-
Insert Size (bp)720
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pET:ACAT:GFP was a gift from Matthew Bennett (Addgene plasmid # 60740 ; http://n2t.net/addgene:60740 ; RRID:Addgene_60740) -
For your References section:
Library of synthetic transcriptional AND gates built with split T7 RNA polymerase mutants. Shis DL, Bennett MR. Proc Natl Acad Sci U S A. 2013 Mar 26;110(13):5028-33. doi: 10.1073/pnas.1220157110. Epub 2013 Mar 11. 10.1073/pnas.1220157110 PubMed 23479654
