pET:GCAT:GFP
(Plasmid #60736)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 60736 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pET-28b
  • Backbone size w/o insert (bp) 5273
  • Total vector size (bp) 5993
  • Modifications to backbone
    No lacO site downstream of T7 promoter. Nucleotides between -11 and -8 are 'GACG'.
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH10B
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    GFP
  • Alt name
    Bba_E0040
  • Insert Size (bp)
    720

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pET:GCAT:GFP was a gift from Matthew Bennett (Addgene plasmid # 60736 ; http://n2t.net/addgene:60736 ; RRID:Addgene_60736)

  • For your References section:

    Library of synthetic transcriptional AND gates built with split T7 RNA polymerase mutants. Shis DL, Bennett MR. Proc Natl Acad Sci U S A. 2013 Mar 26;110(13):5028-33. doi: 10.1073/pnas.1220157110. Epub 2013 Mar 11. 10.1073/pnas.1220157110 PubMed 23479654
