pENTR-DMD-Donor
(Plasmid
#60605)
-
PurposeKnock-in donor vector to insert Exon 44 in front of Exon 45 of human DYSTROPHIN (DMD)gene, include EF1a-hygromycin resistance cassette flanked by loxP sequences.
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 60605 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepENTR2B
-
Backbone manufacturerInvitrogen
- Backbone size w/o insert (bp) 3755
- Total vector size (bp) 7250
-
Vector typeMammalian Expression ; Knock-in donor vector
-
Selectable markersHygromycin
Growth in Bacteria
-
Bacterial Resistance(s)Kanamycin, 50 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameHygromycin resistant gene
-
Alt nameHygroR
-
SpeciesSynthetic
-
Insert Size (bp)1026
Cloning Information
- Cloning method Gibson Cloning
- 5′ sequencing primer N.A.
- 3′ sequencing primer N.A. (Common Sequencing Primers)
Resource Information
-
Articles Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pENTR-DMD-Donor was a gift from Akitsu Hotta (Addgene plasmid # 60605 ; http://n2t.net/addgene:60605 ; RRID:Addgene_60605) -
For your References section:
Precise Correction of the Dystrophin Gene in Duchenne Muscular Dystrophy Patient Induced Pluripotent Stem Cells by TALEN and CRISPR-Cas9. Li HL, Fujimoto N, Sasakawa N, Shirai S, Ohkame T, Sakuma T, Tanaka M, Amano N, Watanabe A, Sakurai H, Yamamoto T, Yamanaka S, Hotta A. Stem Cell Reports. 2014 Nov 25. pii: S2213-6711(14)00335-X. doi: 10.1016/j.stemcr.2014.10.013. 10.1016/j.stemcr.2014.10.013 PubMed 25434822
