Cas9 MDC32
(Plasmid #59185)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 59185 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pMDC32
  • Backbone manufacturer
    Mark D Curtis
  • Vector type
    Plant Expression, CRISPR
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Growth instructions
    Plasmid might grow slower in DH5alpha than other plasmids due to Cas9
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    Glycine Max codon optimized Cas9
  • Alt name
    Cas9
  • Species
    Glycine Max
  • Insert Size (bp)
    4140
  • Promoter 2X35S

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site SalI (not destroyed)
  • 3′ cloning site PacI (not destroyed)
  • 5′ sequencing primer M13_forward20_primer
  • 3′ sequencing primer M13_reverse_primer
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Cas9 MDC32 was a gift from Robert Stupar (Addgene plasmid # 59185)

  • For your References section:

    CRISPR/Cas mutagenesis of soybean and Medicago truncatula using a new web-tool and a modified Cas9 enzyme. Michno JM, Wang X, Liu J, Curtin SJ, Kono TJ, Stupar RM. GM Crops Food. 2015;6(4):243-52. doi: 10.1080/21645698.2015.1106063. 10.1080/21645698.2015.1106063 PubMed 26479970
