PurposeExpresses the calcium sensor GCaMP5G in the mitochondria
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 58509 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backboneFCK(1.3)GW, from Addgene 22217
- Backbone size w/o insert (bp) 9240
- Total vector size (bp) 10059
-
Vector typeMammalian Expression, Lentiviral
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)Stbl3
-
Growth instructionsUse recombinase-free E. coli.
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert name1xCox8 - GCaMP5G
-
SpeciesR. norvegicus (rat), G. gallus (chicken); A. victoria (jellyfish)
-
Insert Size (bp)1458
-
GenBank ID
- Promoter a-CamKII
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer GCTCGTCAATCAAGCTGGTTC
- 3′ sequencing primer CCACATAGCGTAAAAGGAGCAAC (Common Sequencing Primers)
Resource Information
-
A portion of this plasmid was derived from a plasmid made byThe backbone of this plasmid was derived from Addgene plasmid 22217 (from the Boyden Lab at MIT), cut with BamHI and EcoRI. The Cox8 mitochondrial targeting sequence was amplified from Addgene plasmid 23348, mito-PAGFP. The calcium sensor GCaMP5G (Addgene plasmid 31788) was obtained from Loren Looger, Douglas Kim, and Jasper Akerboom.
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Please see Addgene plasmid 31788 for more information on GCaMP5G; also note that GCaMP5G was published in: Optimization of a GCaMP calcium indicator for neural activity imaging. Akerboom et al (J Neurosci. 2012 Oct 3;32(40):13819-40. doi: 10.1523/JNEUROSCI.2601-12.2012.)
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
VV073: 1xCox8 - GCaMP5G in fubi was a gift from Adam Cohen (Addgene plasmid # 58509 ; http://n2t.net/addgene:58509 ; RRID:Addgene_58509) -
For your References section:
Imaging GFP-Based Reporters in Neurons with Multiwavelength Optogenetic Control. Venkatachalam V, Cohen AE. Biophys J. 2014 Oct 7;107(7):1554-63. doi: 10.1016/j.bpj.2014.08.020. 10.1016/j.bpj.2014.08.020 PubMed 25296307
