Addgene

FRP1641_PTEF-HygMX-TTEF-insul-(lexA-box)3-PminCYC1
(Plasmid #58441)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 58441 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBS
  • Backbone manufacturer
    Stratagene
  • Backbone size w/o insert (bp) 2884
  • Total vector size (bp) 4914
  • Vector type
    Yeast Expression
  • Selectable markers
    Hygromycin

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    PTEF-HygMX-TTEF-insul-(lexA-box)3-PminCYC1
  • Species
    Synthetic
  • Insert Size (bp)
    2030
  • Promoter PTEF-HygMX-TTEF-insul-(lexA-box)3-PminCYC1

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XhoI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer TAATACGACTCACTATAGGG
  • 3′ sequencing primer AATTAACCCTCACTAAAGGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    FRP1641_PTEF-HygMX-TTEF-insul-(lexA-box)3-PminCYC1 was a gift from Joerg Stelling (Addgene plasmid # 58441 ; http://n2t.net/addgene:58441 ; RRID:Addgene_58441)

  • For your References section:

    Inducible, tightly regulated and growth condition-independent transcription factor in Saccharomyces cerevisiae. Ottoz DS, Rudolf F, Stelling J. Nucleic Acids Res. 2014 Jul 17. pii: gku616. 10.1093/nar/gku616 PubMed 25034689
