pL-CRISPR.SFFV.GFP
(Plasmid #57827)

• Purpose: Lentiviral CRISPR-Cas9 delivery for SpCas9 and sgRNA. Coexpresses eGFP via P2A cleavage site. SFFV Promoter driven
• Depositing Lab: Benjamin Ebert
• Publication: Heckl et al Nat Biotechnol. 2014 Jun 22. doi: 10.1038/nbt.2951.

Backbone

• Vector backbone: pLKO.005
• Total vector size (bp): 13615
• Vector type: Lentiviral, CRISPR

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): Stbl3
• Copy number: High Copy

Gene/Insert 1

• Gene/Insert name: SpCas9
• Species: S. pyogenes
• Insert Size (bp): 4300

Gene/Insert 2

• Gene/Insert name: Sp sgRNA scaffold
• Insert Size (bp): 75
• Tag / Fusion Protein:
  • FLAG (N terminal on insert)

Gene/Insert 3

• Gene/Insert name: SFFV
• Alt name: Spleen Focus Forming Virus promoter
• Species: Synthetic
• Insert Size (bp): 415

Gene/Insert 4

• Gene/Insert name: P2A-eGFP
• Species: Synthetic
• Insert Size (bp): 750

Resource Information

• Supplemental Documents:
  • Target site cloning protocol
• Articles Citing this Plasmid:
  • 14 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Please note that this plasmid contains the 1.9kb stuffer from the pLKO.005 vector backbone between the BsmBI sites used for sgRNA cloning.
