Kaede-N1
(Plasmid #54726)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 54726 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    Kaede-N1
  • Backbone size (bp) 4750
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)
  • Tag / Fusion Protein
    • Kaede (C terminal on backbone)

Growth in Bacteria

  • Bacterial Resistance(s)
    Kanamycin, 50 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    None
  • Tag / Fusion Protein
    • Kaede (C terminal on backbone)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

. Excitation = 508 / 572; Emission = 518 / 580

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Kaede-N1 was a gift from Michael Davidson (Addgene plasmid # 54726 ; http://n2t.net/addgene:54726 ; RRID:Addgene_54726)

  • For your References section:

    Photoconversion in orange and red fluorescent proteins. Kremers GJ, Hazelwood KL, Murphy CS, Davidson MW, Piston DW. Nat Methods. 2009 May;6(5):355-8. doi: 10.1038/nmeth.1319. Epub 2009 Apr 12. 10.1038/nmeth.1319 PubMed 19363494
