Addgene

pMZ286
(Plasmid #52227)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 52227 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pMZ283
  • Backbone size w/o insert (bp) 6181
  • Total vector size (bp) 6201
  • Vector type
    Yeast Expression, CRISPR
  • Selectable markers
    ura4

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Top10
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    rrk1-sgRNA
  • Species
    S. pombe (fission yeast)
  • Promoter rrk1

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site CspCI (destroyed during cloning)
  • 3′ cloning site CspCI (destroyed during cloning)
  • 5′ sequencing primer CAG GAA ACA GCT ATG AC
  • 3′ sequencing primer TGT AAA ACG ACG GCC AGT
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pMZ286 was a gift from Mikel Zaratiegui (Addgene plasmid # 52227 ; http://n2t.net/addgene:52227 ; RRID:Addgene_52227)

  • For your References section:

    Implementation of the CRISPR-Cas9 system in fission yeast. Jacobs JZ, Ciccaglione KM, Tournier V, Zaratiegui M. Nat Commun. 2014 Oct 29;5:5344. doi: 10.1038/ncomms6344. 10.1038/ncomms6344 PubMed 25352017
