Nano-lantern(Ca2+)_300/pcDNA3
(Plasmid
#51983)
-
Purposemammalian expression of a Nano-lantern-based luminescent Ca2+ indicator with Kd=300nM
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 51983 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3
-
Backbone manufacturerInvitrogen
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameNano-lantern_CaM_E104Q-3GS
-
SpeciesSynthetic
-
Insert Size (bp)2200
-
MutationS257G in Rluc8
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site EcoRI (not destroyed)
- 5′ sequencing primer CMV-F
- 3′ sequencing primer BGHrev (Common Sequencing Primers)
Resource Information
-
Addgene Notes
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
GenBank accession number: JN859497
The minor discrepancies between the QC and depositor sequence have no functional consequence.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
Nano-lantern(Ca2+)_300/pcDNA3 was a gift from Takeharu Nagai (Addgene plasmid # 51983 ; http://n2t.net/addgene:51983 ; RRID:Addgene_51983) -
For your References section:
Luminescent proteins for high-speed single-cell and whole-body imaging. Saito K, Chang YF, Horikawa K, Hatsugai N, Higuchi Y, Hashida M, Yoshida Y, Matsuda T, Arai Y, Nagai T. Nat Commun. 2012;3:1262. doi: 10.1038/ncomms2248. 10.1038/ncomms2248 PubMed 23232392
