Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 51383 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepcDNA3
-
Backbone manufacturerInvitrogen
-
Vector typeMammalian Expression
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberHigh Copy
Gene/Insert
-
Gene/Insert nameDGCR8
-
SpeciesH. sapiens (human)
-
Insert Size (bp)2322
-
Entrez GeneDGCR8 (a.k.a. C22orf12, DGCRK6, Gy1, pasha)
- Promoter CMV
-
Tag
/ Fusion Protein
- V5 (N terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site EcoRI (not destroyed)
- 3′ cloning site NotI (not destroyed)
- 5′ sequencing primer CAATGGGCGTGGATAGCG
- 3′ sequencing primer CCAGGGTCAAGGAAGGCAC (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
Addgene Quality Control sequencing has found some discrepancies in the full plasmid sequence in the V5 tag and liner region of the plasmid. The V5 tag and DGCR8 insert are not effected.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pcDNA3-V5-DGCR8 was a gift from Narry Kim (Addgene plasmid # 51383 ; http://n2t.net/addgene:51383 ; RRID:Addgene_51383) -
For your References section:
Characterization of DGCR8/Pasha, the essential cofactor for Drosha in primary miRNA processing. Yeom KH, Lee Y, Han J, Suh MR, Kim VN. Nucleic Acids Res. 2006;34(16):4622-9. Epub 2006 Sep 8. 10.1093/nar/gkl458 PubMed 16963499
