pU6-neo-TET
(Plasmid
#51286)
-
Purposeexpresses U6 RNA, using its own pol III enhancer sequence and tagged with the self splicing intron neo cassette
-
Depositing Lab
-
Sequence Information
Ordering
Item | Catalog # | Description | Quantity | Price (USD) | |
---|---|---|---|---|---|
Plasmid | 51286 | Standard format: Plasmid sent in bacteria as agar stab | 1 | $85 |
Backbone
-
Vector backbonepAluYa5-neo-TET
-
Backbone manufacturerAddgene plasmid 51283
-
Vector typeMammalian Expression
-
Selectable markersNeomycin (select with G418)
Growth in Bacteria
-
Bacterial Resistance(s)Ampicillin, 100 μg/mL
-
Growth Temperature37°C
-
Growth Strain(s)DH5alpha
-
Copy numberUnknown
Gene/Insert
-
Gene/Insert nameU6
-
Alt nameHUMUG6
-
SpeciesH. sapiens (human)
-
Insert Size (bp)512
-
Entrez GeneRNU6-1 (a.k.a. RNU6, RNU6A, U6, U6-1)
- Promoter U6 upstream enhancer sequence
-
Tag
/ Fusion Protein
- neoTET cassette with a tetrahymena self-splicing intron interrupting the neo gene (C terminal on backbone)
Cloning Information
- Cloning method Restriction Enzyme
- 5′ cloning site BamHI (not destroyed)
- 3′ cloning site AatI (not destroyed)
- 5′ sequencing primer M13-pUC-Fwd
- 3′ sequencing primer SV40pro-F (Common Sequencing Primers)
Resource Information
-
Article Citing this Plasmid
Terms and Licenses
-
Academic/Nonprofit Terms
-
Industry Terms
- Not Available to Industry
Trademarks:
- Zeocin® is an InvivoGen trademark.
Depositor Comments
U6 is tagged with the self splicing intron neo cassette such that G418 resistance will be obtained only if retrotransposition occurs.
Please note that the cassette is in the reverse orientation within the MCS relative to the full sequence--This has no functional consequence.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
-
For your Materials & Methods section:
pU6-neo-TET was a gift from Astrid Roy-Engel (Addgene plasmid # 51286 ; http://n2t.net/addgene:51286 ; RRID:Addgene_51286) -
For your References section:
The RNA polymerase dictates ORF1 requirement and timing of LINE and SINE retrotransposition. Kroutter EN, Belancio VP, Wagstaff BJ, Roy-Engel AM. PLoS Genet. 2009 Apr;5(4):e1000458. doi: 10.1371/journal.pgen.1000458. Epub 2009 Apr 24. 10.1371/journal.pgen.1000458 PubMed 19390602
