U6-BbsI-crRNA
(Plasmid #51026)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 51026 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pBS-SK(-)
  • Backbone manufacturer
    Agilent
  • Backbone size w/o insert (bp) 2950
  • Total vector size (bp) 3447
  • Vector type
    Insect Expression, CRISPR

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    U6-BbsI-crRNA
  • Alt name
    U6-SpcrRNA
  • Alt name
    CRISPR RNA (crRNA)
  • Insert Size (bp)
    500
  • Promoter U6-2

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site EcoRV (destroyed during cloning)
  • 3′ cloning site EcoRV (destroyed during cloning)
  • 5′ sequencing primer T7
  • 3′ sequencing primer T3
    • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The design of this plasmid is based on the pre-crRNA plasmid described in Cong et al. 2013.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    U6-BbsI-crRNA was a gift from Melissa Harrison & Kate O'Connor-Giles & Jill Wildonger (Addgene plasmid # 51026 ; http://n2t.net/addgene:51026 ; RRID:Addgene_51026)
