pHAGE TRE dCas9
(Plasmid #50915)

• Purpose: Tet-regulatable dCas9 lentiviral expression vector
• Depositing Labs: Rene Maehr, Scot Wolfe
• Publication: Kearns et al Development. 2014 Jan;141(1):219-23. doi: 10.1242/dev.103341.

Backbone

• Vector backbone: pHAGE
• Total vector size (bp): 14433
• Vector type: Mammalian Expression, Lentiviral, CRISPR
• Selectable markers: Neomycin (select with G418)

Growth in Bacteria

• Bacterial Resistance(s): Ampicillin, 100 μg/mL
• Growth Temperature: 37°C
• Growth Strain(s): XL1 Blue
• Copy number: High Copy

Gene/Insert

• Gene/Insert name: dCas9
• Species: S. pyogenes
• Insert Size (bp): 4312
• Mutation: D10A, H840A
• Promoter: TRE

Cloning Information

• Cloning method: Gateway Cloning
• 5′ sequencing primer: AGAGCTCGTTTAGTGAACCG

Resource Information

• Articles Citing this Plasmid:
  • 3 References

Terms and Licenses

• Academic/Nonprofit Terms:
  • UBMTA
• Industry Terms:
  • Not Available to Industry

Depositor Comments

Please note that there are several mismatches (minor deletions and insertions) between depositor's reference sequence and Addgene's quality control sequence. The mismatches are in cloning junctions/non-coding regions and should not affect plasmid function.
