pBL6
(Plasmid #50549)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 50549 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pSB4A3
  • Backbone manufacturer
    Registry of Standard Biological Parts
  • Backbone size w/o insert (bp) 3296
  • Total vector size (bp) 4242
  • Vector type
    Bacterial Expression, Synthetic Biology

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    Top10
  • Copy number
    Low Copy

Gene/Insert

  • Gene/Insert name
    mCherry
  • Species
    Synthetic
  • Insert Size (bp)
    946

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

Note: Addgene's quality control sequencing found a few mismatches compared to the depositor's full sequence, but they should not affect plasmid function.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pBL6 was a gift from Jeffrey Tabor (Addgene plasmid # 50549 ; http://n2t.net/addgene:50549 ; RRID:Addgene_50549)

  • For your References section:

    Characterizing bacterial gene circuit dynamics with optically programmed gene expression signals. Olson EJ, Hartsough LA, Landry BP, Shroff R, Tabor JJ. Nat Methods. 2014 Mar 9. doi: 10.1038/nmeth.2884. 10.1038/nmeth.2884 PubMed 24608181
