pcDNA3.1(-)-HA-SrtAstrep (pKS77)
(Plasmid #50030)

Print

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 50030 Standard format: Plasmid sent in bacteria as agar stab 1 $85
Add to Cart

Backbone

  • Vector backbone
    pcDNA3.1(-)
  • Backbone manufacturer
    Invitrogen
  • Backbone size w/o insert (bp) 5500
  • Total vector size (bp) 6000
  • Vector type
    Mammalian Expression
  • Selectable markers
    Neomycin (select with G418)

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    Unknown

Gene/Insert

  • Gene/Insert name
    SrtA(strep)
  • Species
    Streptococcus pyogenes
  • Insert Size (bp)
    591
  • Promoter pCMV
  • Tag / Fusion Protein
    • HA (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site XbaI (not destroyed)
  • 3′ cloning site XhoI (not destroyed)
  • 5′ sequencing primer TAATACGACTCACTATAGGG
  • 3′ sequencing primer TAGAAGGCACAGTCGAGG
    • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pcDNA3.1(-)-HA-SrtAstrep (pKS77) was a gift from Hidde Ploegh (Addgene plasmid # 50030 ; http://n2t.net/addgene:50030 ; RRID:Addgene_50030)

  • For your References section:

    Protein ligation in living cells using sortase. Strijbis K, Spooner E, Ploegh HL. Traffic. 2012 Jun;13(6):780-9. doi: 10.1111/j.1600-0854.2012.01345.x. Epub 2012 Mar 23. 10.1111/j.1600-0854.2012.01345.x PubMed 22348280
